Product advantages

1, The use of special UV lamps placed on the products have a good drying effect;

2, The use of removable UV lamp device to reduce the number of UV lamps, saving power;

3, UV lamp moving speed can be adjusted, in order to achieve the best results of drying;

4, The use of imported or domestic lamp and reflector, lamp intensity of light intensity selection device, the reflector can effectively reflect 95% of the light source;

5, The device has a flip inside the device can automatically flip, so that both sides of the wooden doors to achieve the effect of dry.



Product parameters

Physical dimension 2.5x1.6x1.85m Fan pressure 693/1022pa
Pump lamp lamp power 11KW x 5 Conveyor motor power 075KW
Pump light wavelength 350-450mm Using power 380V 50Hz
Exhaust fan power 1.1KW
Air volume of fan 1250/2250m³/h
